Controls Catalogue 2016

9 / 20

BO2 AO4
BACnet
MS/TP
DI1 AI3
BAC
Inputs
Outputs
Communication
1 Digital
(alarm status)
3 Analog 24 Vac
2 Digital 4 Analog
Main Features
• BACnet MS/TP (stand-alone model HRO20 also
available)
• 4 analog outputs and 2 dry contact outputs
• External humidity sensor input
• Window or external temperature sensor input
• Alarm status and low signal selector input
• Independently configure PID on humidify & dehumidify
ramps
• Adjustable setpoint with auto reset from external sensor
• Multi level lockable access menu, setpoint and control
mode
• Backlit LCD with simple icon and text driven menus
• Selectable Celsius or Fahrenheit scale
• Humidification and dehumidification indicator
nep t r on i c . com
Wall Mount Humidity Controller
Combination controller and room humidistat.
Run control wires directly to HROB unit.
Applications
• Neptronic SKR, SK300, SKE, and SKG humidifiers
• Other humidification and dehumidification applications
Ramps
• LSS: External Demand Low Signal Selector
Compares selected input signals to select the
lowest signal.
• AER: External Humidity Sensor Averaging
Calculates an average of selected input signals
• DUC: Duct Supply Input
Two PID loops and a zero/span to smooth out the
demand signal
• DED: External Demand Signal
Control using an external demand of 0-10Vdc or
2-10Vdc
• HIL: High limit
Compares the demand of the room humidity PID
loop with the duct/high limit PID loop and applies
the lower of the two.
Humidity Control
Wall Mount Controller
*Configurable
