12 / 20
BACnet
MS/TP
BAC
Communication
DI1 AI1
Inputs
1
Digital
(occ. sensor)
1
Analog
(ext. temp.
sensor)
24
Vac/
24
Vdc
BACnet Sensors
Models
Main Features
•
Built-in sensor(s)
-Temperature (STRB24)
-Temperature and Humidity (SHRB24)
•
External temperature sensor input
•
Occupancy sensor input
•
BACnet MS/TP @ 9600, 19200, 38400 or 76800 bps
•
10 BACnet objects
•
Automatic baud rate detection
•
Automatic device instance configuration
STRB and SHRBnep t r on i c . com
BACnet Room Sensors
Networkable wall mounted temperature and humidity room
sensors
STRB24
Yes
-
SHRB24
Yes
Yes
Model
Temp Humidity
SMBR
BACnet Router
Main Features
•
One page, set-and-forget configuration and unique network
discovery capabilities minimize installation time
•
Up to 32 or 64 BACnet devices without the use of
additional line drivers
•
DeviceFind™ discovery feature: enables you to discover
BACnet devices connected to the router with one push of a
button (minimizes time required for successful
commissioning)
•
Lowest cost per connected MS/TP device
•
Lowest response time per connected MS/TP device
SMBR1 1-Port Router
Up to 32
SMBR2 2-Port Router
Up to 64
Model
Description BACnet
Devices
