TUCB24C6X2 2
2
6
2
Temp.
TUHB24C6X2 2
2
6
2 Temp. / Hum.
Universal
Wall Mount Controller
DI2 AI2
BO6 AO2
BAC
Model
Main Features
•
Applications: Heat pump, humidity control, CO 2 alarms,
or general unit controller
•
Precise temperature control with programmable PI
function
•
Selectable internal or external temperature sensor
•
External humidity sensor input
•
Built-in humidity sensor (TUHB models only)
•
Dehumidification sequence compensated by auto
activation of reheat output
•
Changeover by contact or external temperature sensor
•
Compressor anti-cycling delay (configurable)
•
Low limit set protection (10°C/50°F)
•
Freeze protection
•
Occupancy and Night Set Back (NSB) mode
•
Real time clock (RTC) with 24-hour backup
•
BACnet MS/TP or Modbus communication (selectable)
•
7-day BACnet schedule
•
Backlit LCD with simple icon and text driven menus
•
Selectable Fahrenheit or Celsius scale
•
Manual no occupancy override
•
Multi level lockable access menu and setpoint
Inputs
Outputs
Communication
2
Digital
2
Analog*
24
Vac
6
Digital*
2
Analog*
1,2
or
3
* Speed (BO3-BO6)
or
ECM
(AO2)
BACnet
MS/TP
Wall Mount Universal Controller
Combination controller and room thermostat.
Run control wires directly to TUCB unit.
TUCB/TUHBUniversal Applications
•
Heat pumps
•
Packaged AC rooftop units
•
Fan coils
•
Humidity control
•
CO 2 alarms
•
Other heating/cooling equipment
Mod
Modbus
RTU Slave
Packaged AC
Rooftop Units
Heat Pumps
Fan Coils
*Configurable
*fully configurable for universal applications
Model
DI*
AI*
BO* AO*
Sensor
