11 / 20
SW
2
Override
Switches
AI2
BO2
BAC
Inputs
Outputs
Communication
2
Analog*
(universal)
120
or
240
Vac
(selectable)
2
Digital*
BACnet
MS/TP
*Configurable
Models
Main Features
•
BACnet MS/TP
•
2 inputs and 2 supervised outputs
•
2 override switches to manually control each output
•
LED status indication of each input and output
•
120Vac or 240 Vac selectable power input
•
2 auxiliary outputs (24Vdc / 24Vac)
CMMB1322
BACnet MS/TP
2
2
Type
Network
Inputs Outputs
Applications
The CMMB extends your BACnet network when your
application requires additional inputs and outputs on a
physical controller. The CMMB provides simple
expansion of a new or existing controller and reduces
unnecessary costs of additional components.
nep t r on i c . com
CMMB1322Remote BACnet I/O Board
Input and output expansion board (CMMB)
24
Vdc and
24
Vac
(aux. output)
Input / Output
Expansion Controller
