TUUB | Wall Mount Universal Controller
- Universal applications
- Fully configurable: 4 inputs & 10 outputs
- 1 to 3 speed or analog (ECM) fan control
- BMS integration via BACnet MS/TP or Modbus
- BACnet scheduler
- Universal applications
- Fully configurable: 4 inputs & 8 outputs
- 1 to 3 speed or analog (ECM) fan control
- BMS integration via BACnet MS/TP or Modbus
- BACnet scheduler
-
TUUB
Wall Mount Universal
Controller
-
TUCB & TUHB
Wall Mount Universal
Controller
TUUB
- Wall Mount Universal Controller
TUCB/TUHB
- Wall Mount Universal Controller
-
Packaged AC
Rooftop Units
-
Heat Pumps
-
Fan Coils
Details
- Built in temperature sensor andoptional humidity, VOC , CO2 and occupancy sensors(select models)
- Real time clock (RTC) with 24-hour backup
- Precise temperature control with configurable PI (Proportional-Integral) function
- Selectable internal or external temperature sensor
- Occupancy and night set back (NSB) mode
- Option of pulse/floating/on-off output on binary outputs
- Compressor anti-cycling delay (configurable)
- ΔT control (on request)
- Selectable BACnet MS/TP or Modbus communication
- BACnet MS/TP or Modbus communication (selectable via menu)
- Select MAC address via menu or via network
- Automatic baud rate detection
BACnet MS/TP
- Automatic device instance configuration
- Copy & broadcast configuration via menu or via BACnet to other controllers
- BACnet scheduler (up to 6 events per day)
- Firmware upgradeable via BACnet
- Supports COV (change of value)
Modbus
- Modbus @ 9600, 19200, 38400, or 57600 bps
- RTU Slave, 8 bits (configurable parity and stop bits)
- Connects to any Modbus master
- Fan coil units (2 or 4 pipes)
- Rooftop units
- Heat pumps
- Humidity control
- Packaged or split unitary systems
- Other heating/cooling equipment
Models
|
|
$ 694 |
• |
|
|
|
|
|
|
$ 1,062 |
• |
• |
|
|
|
|
|
$ 1,555 |
• |
• |
• |
|
|
|
|
$ 1,186 |
• |
|
• |
|
|
|
|
$ 793 |
• |
|
|
• |
|
|
|
$ 1,161 |
• |
• |
|
• |
|
|
|
$ 2,048 |
• |
• |
• |
|
• |
|
|
$ 2,147 |
• |
• |
• |
• |
• |
-
Packaged AC
Rooftop Units
-
Heat Pumps
-
Fan Coils
Details
- Fully configurable inputs (x4) and outputs (x8)
- Fan control: 1, 2, or 3-speed (auto/on), or analog (ECM)
- Selectable internal or external temperature sensor
- External humidity sensor input for simple and accurate humidity control
- Built-in humidity sensor (only with TUHB models)
- Dehumidification sequence compensated by auto activation of reheat output
- Inputs and outputs configurable for CO2 sensor and alarm
- Real time clock (RTC) with 24-hour backup
- Precise temperature control with configurable PI (Proportional-Integral) function
- Anti-freeze protection
- Compressor anti-cycling delay (configurable)
- Low limit set protection (10°C / 50°F)
- Occupancy and night set back (NSB) mode
- Selectable direction on outputs
- BACnet MS/TP or Modbus communication (selectable via menu)
- Select MAC address via menu or via network
- Automatic baud rate detection
BACnet MS/TP
- Automatic device instance configuration
- Copy & broadcast configuration via menu or via BACnet to other controllers
- BACnet scheduler (up to 6 events per day)
- Firmware upgradeable via BACnet
- Supports COV (change of value)
Modbus
- Modbus @ 9600, 19200, 38400, or 57600 bps
- RTU Slave, 8 bits (configurable parity and stop bits)
- Connects to any Modbus master
Models
* fully configurable for universal applications
- Heat pumps
- Packaged AC rooftop units
- Fan coils
- Humidity control
- CO2 alarms
- Other heating/cooling equipment
