Standard Features
• Accepts any industry standard input signal
• Quick and simple input signal selection via DIP switches
• Modulating, on/off, and/or up to 10 stages
• Real-time feedback output of heater capacity
• Automatic PID
• Remote feedback with TRL54 or TRL24 LCD thermostat
(eliminates the use of expensive staged thermostats)
• Zero voltage crossing SSR
• Patented EAS Electronic Air Flow Sensors (US 7,012,223)
Network Communication
• BACnet MS/TP or Modbus RTU (selectable via DIP switch)
• Select MAC address via DIP switch or via network
BACnet MS/TP
• MS/TP @9600, 19200, 38400 or 76800 bps
• BACnet scheduler (up to 6 events)
• Firmware upgradeable via network
• COV (change of value)
• Copy and broadcast configuration to other HECB
controllers via menu or network
• Automatic baud rate detection
• Automatic device instance configuration
Modbus RTU
• Modbus RTU @9600, 19200, 38400 or 57600 bps
• RTU Slave, 8 bits (configurable parity and stop bits)
• Connects to any Modbus RTU master
Benefits
Save Energy
• Embedded and configurable energy conservation strategies
• Automatic or dynamic load shedding
• Limit electric heater consumption based on multiple
variables
• Provides real-time temperature measures and power
consumption data
Save Time
• View heater status and alarms remotely via network or
thermostat
• Remote monitoring (status, alarms, diagnostics, and
trending)
• Wall-mount remote user interface (view temperature,
setpoint, heater status and alarms)
Integrate
• Integrate with BMS and intelligent buildings via BACnet
MS/TP or Modbus
• Multiple BACnet/Modbus points to propel you towards the
Internet of Things (IoT)
• Ensure better management of energy consumption for the
future
HECB Networkable Controller
