1, 2, 3 Start your humidifiers!
You have installed a new Neptronic SK humidifier (SKE4, SKG4, SKS4 and SKVF series) connected with a humidity sensor (in the room or return duct).
The final stage to complete the installation is to program the humidifier to operate as a standalone unit. Follow these 3 steps to configure the humidifier
to function with a remote humidity sensor:
Step 1. Configuration
- Access the Installation menu, login 4433
- Select Control, Control Profile, set to Internal Analog (enter)
- Select Room Demand Loop, RHStptSrc, set to Internal (enter)
- Keep the default values for the remaining items in this menu.
- Exit this menu.
| Control |
| ControlProfile: |
ExternAnalog |
ExternAnalog, ExternNetwork,
InternAnalog,
InternNetwork, HRL,
Custom |
| ModHLProfile: |
Disabled |
Disabled, ExternAnalog,
ExternNetwork, InternAnalog,
InternNetwork, Custom |
| RoomDemandLoop |
PropGain:
IntgrlTime:
DrvtveTime:
PropBand:
RHSrc:
RHStptSrc:
|
20.0
0.0sec
0.0sec
5.0%
RoomRH
None
|
min: 1.0, max: 200.0
min: 0.0sec, max: 900.0sec
min: 0.0sec, max: 60.0sec
min: 1.0%, max: 100.0%
None, RoomRH, Network, HRL
None, Internal, ControlInput
|
Step 2. Adjust Set Point
- Access the User Setting menu, login 4433
- Select Control, Room Demand Loop, RoomRHStp, set the value to the required set point that you wish to maintain the in the space (enter)
- Exit this menu.
| Control |
| RoomDemandLoop |
RoomRHStp:
RoomRHUnocStp:
RoomRHVacStp
|
40.0%
30.0%
20.0%
|
min: 0.0%, max: 100.0%
min: 0.0%, max: 100.0%
min: 0.0%, max: 100.0%
|
Step 3. View the %RH value
- Access the General menu
- Select Physical IO, Room RH to view the %RH value read by the external humidity sensor.
- When the RoomRHStp value is above the Room RH then a Humidity Demand will be displayed on the Idle Screen.
- Exit this menu.
| Physical IO |
BinExtDemand:
ControlInput:
RoomRH
|
0%
Current value
Current value
|
* (min: 0%, max: 100%)
* (min: 0%, max: 100%)
* (min: 0%, max: 100%)
|
You have completed the programing of the humidifier!
Turn the unit On by pressing and holding the Power button for three seconds, the blue led will turn On.
