NPT Female
Actuator Models - 24VAC/30VDC Supply
Brass Body & Chrome Plated Ball
MODULATING (0) 2-10VDC, 4-20mA
Valve Size
Cv
Kv
Valve Model Prefix
Close Off PSI
Standard + Mech. Switches
Actuator with Fail Safe
(Enerdrive)
SM000S
SM060S
3/4”
4.7/4.7
4/4
B6B047-047
200
$ 1,090.00
$ 1,238.00

3/4”
4.7/7.4
4/6.4
B6B047-074
200
$ 1,090.00
$ 1,238.00

3/4”
4.7/10
4/8.6
B6B047-100
200
$ 1,090.00
$ 1,238.00

3/4”
4.7/14
4/12
B6B047-140
200
$ 1,090.00
$ 1,238.00

3/4”
7.4/4.7
6.4/4
B6B074-047
200
$ 1,090.00
$ 1,238.00

3/4”
7.4/7.4
6.4/6.4
B6B074-074
200
$ 1,090.00
$ 1,238.00

3/4”
7.4/10
6.4/8.6
B6B074-100
200
$ 1,090.00
$ 1,238.00

3/4”
7.4/14
6.4/12
B6B074-140
200
$ 1,090.00
$ 1,238.00

3/4”
10/4.7
8.6/4
B6B100-047
200
$ 1,090.00
$ 1,238.00

3/4”
10/7.4
8.6/6.4
B6B100-074
200
$ 1,090.00
$ 1,238.00

3/4”
10/10
8.6/8.6
B6B100-100
200
$ 1,090.00
$ 1,238.00

3/4”
10/14
8.6/12
B6B100-140
200
$ 1,090.00
$ 1,238.00

3/4”
14/4.7
12/4
B6B140-047
200
$ 1,090.00
$ 1,238.00

3/4”
14/7.4
12/6.4
B6B140-074
200
$ 1,090.00
$ 1,238.00

3/4”
14/10
12/8.6
B6B140-100
200
$ 1,090.00
$ 1,238.00

3/4”
14/14
12/12
B6B140-140
200
$ 1,090.00
$ 1,238.00

NPT Female
Actuator Models - 24VAC/30VDC Supply
Brass Body & Chrome Plated Ball
MODULATING (0) 2-10VDC, 4-20mA
Valve Size
Cv
Kv
Valve Model Prefix
Close Off PSI
Standard Actuator
Actuator with Fail Safe
(Enerdrive)
LM000
LM060
1
7.4/7.4
6.4/6.4
B6C074-074
200
$ 1,335.00
$ 1,571.00

1
7.4/10
6.4/8.6
B6C074-100
200
$ 1,335.00
$ 1,571.00

1
7.4/19
6.4/16
B6C074-190
200
$ 1,335.00
$ 1,571.00

1
10/7.4
8.6/6.4
B6C100-074
200
$ 1,335.00
$ 1,571.00

1
10/10
8.6/8.6
B6C100-100
200
$ 1,335.00
$ 1,571.00

1
10/19
8.6/16
B6C100-190
200
$ 1,335.00
$ 1,571.00

1
19/7.4
16/6.4
B6C190-074
200
$ 1,335.00
$ 1,571.00

1
19/10
16/8.6
B6C190-100
200
$ 1,335.00
$ 1,571.00

1
19/19
16/16
B6C190-190
200
$ 1,335.00
$ 1,571.00
