TFP24 | Wall Mount Heat Pump Controller

  • Stages: 1 heat & 1 cool
  • Fan, compressor and reversing valve outputs
  • External temperature sensor input
  • Precise temperature control with programmable PI function
  • Adjustable and lockable setpoint
  • Universal applications
  • Fully configurable: 4 inputs & 8 outputs
  • 1 to 3 speed or analog (ECM) fan control
  • BMS integration via BACnet MS/TP or Modbus
  • BACnet scheduler
  • TFP24

    Wall Mount Heat Pump
    Controller
  • TUCB & TUHB

    Wall Mount Universal
    Controller
TFP24 - Wall Mount Heat Pump Controller

Details

Outputs & Inputs
  • Stages: 1 heat & 1 cool
  • 3 dry contact outputs
    • Fan
    • Compressor
    • Reversing valve
  • External temperature sensor input
Operation & Display
  • Wall mounted controller
  • Precise temperature control with programmable PI function
  • Adjustable and lockable setpoint
  • Selectable control mode and fan mode
  • Selectable internal or external temperature sensor
  • Backlit LCD with simple icon and text driven menus
  • Selectable Celsius or Fahrenheit scale

Models

Pricing
Model List Price Description
TFP24C3Y1 $ 241 Stages 1 heat / 1 cool
Applications
  • Single stage heating and colling units
  • Small commercial applications
  • Residential applications
TUCB/TUHB - Wall Mount Universal Controller
  • Packaged AC
    Rooftop Units
  • Heat Pumps
  • Fan Coils

Details

Features
  • Fully configurable inputs (x4) and outputs (x8)
  • Fan control: 1, 2, or 3-speed (auto/on), or analog (ECM)
  • Selectable internal or external temperature sensor
  • External humidity sensor input for simple and accurate humidity control
  • Built-in humidity sensor (only with TUHB models)
  • Dehumidification sequence compensated by auto activation of reheat output
  • Inputs and outputs configurable for CO2 sensor and alarm
  • Real time clock (RTC) with 24-hour backup
  • Precise temperature control with configurable PI (Proportional-Integral) function
  • Anti-freeze protection
  • Compressor anti-cycling delay (configurable)
  • Low limit set protection (10°C / 50°F)
  • Occupancy and night set back (NSB) mode
  • Selectable direction on outputs
Network Communication
  • BACnet MS/TP or Modbus communication (selectable via menu)
  • Select MAC address via menu or via network
  • Automatic baud rate detection

BACnet MS/TP

  • Automatic device instance configuration
  • Copy & broadcast configuration via menu or via BACnet to other controllers
  • BACnet scheduler (up to 6 events per day)
  • Firmware upgradeable via BACnet
  • Supports COV (change of value)

Modbus

  • Modbus @ 9600, 19200, 38400, or 57600 bps
  • RTU Slave, 8 bits (configurable parity and stop bits)
  • Connects to any Modbus master

Models

Pricing
Model List Price BI* AI* BO* AO*
TUCB24C6X2 $ 502 2 2 6 2
TUHB24C6X2 $ 807 2 2 6 2
* fully configurable for universal applications
Applications
  • Heat pumps
  • Packaged AC rooftop units
  • Fan coils
  • Humidity control
  • CO2 alarms
  • Other heating/cooling equipment
